General

• High Efficiency up to 158 L/W for selected
• 80 CRI models
• 90 CRI options special order
• Low glare with UGR<18
• Wireless control options
• Over-temperature protection dims to guarantee reliability
  • 65°C/150°F full light output for 105W
  • 45°C/113°F full light output for 150/165W
• Five years or 50,000 hours warranty
• IP52 / UL Wet Listed
• IP65 optional - special order
• Mogul Base, vertical orientation only
• 1.65 kg / 3.6 lb
• Anodized solid aluminum body

Control Options

• Wireless Options:
  • Synpase, Casambi, Avi-On
• Non Wiress Options:
  • Occupancy & Daylight, Manual Power Set
• Dims to 10% then to off
• Controls not compatible with ballast operation

World Wide Qualifications

• UL/ULC, CE/CB, PSE, KC, BSMI, NOM
• DLC Standard
• IP52 / UL damp listed standard
• IP65 / UL wet optional

Mechanical

• Ø 22.64" (575mm) x 17.95" (456mm)

Compatible Accessories

• 22” UGR Diffuser (ACC-022-UGR-000-FL)
• 22” Conical Lens (ACC-022-CNL-000-FL)
• 22” Drop Lens (ACC-022-DRL-000-FL)
• 22” Wireguard Black (ACC-022-WBK-000-FL)

Electrical

• VL: Line Voltage 100-277 VAC, 50-60 Hz
• VH: Hybrid: Ballast Compatible and Line Voltage 100-277 VAC
• < 1% flicker
• 6 kV surge protection, PF>0.9/THD<20%

The Hybrid series is compatible with HID magnetic ballast between 45-250W. Such ballast types include probe start, pulse start, CWA, or reactive. The table below shows compatible ballast that have been tested. Input to ballast may be up to 480V. Optical distribution and lumen output are constant regardless of Ballast type or wattage. Ballast operation is not compatible with controls.
